Product Description
JRV03 PVC-U octagonal ball valve by JARO is made of 100% virgin PVC material for worldwide distributors & OEM clients. Features ANSI/DIN/JIS/BS standards, leak-proof sealing, and flexible ABS/PP/PVC handle configurations. Expand your valves and fittings product line with JARO Industry.
Value Propositions
Octagonal Structural Design for Enhanced Installation Stability
The valve body features an octagonal exterior design, providing multiple stable, load-bearing surfaces. This effectively prevents tools from slipping during installation in tight spaces or on-site, reducing the risk of valve body damage caused by uneven force.
Integrated Male & Female Threaded Connection to Reduce System Nodes
The combined male and female thread design allows for direct connection to water pumps, water tanks, or other equipment interfaces. This minimizes the use of bushings and adapters, thereby reducing potential leak points and simplifying the piping struc
Manufactured from Virgin Materials to Ensure Long-Term Reliable Use
Produced using 100% brand-new PVC raw materials, the valve offers excellent corrosion and aging resistance. It is well-suited for various water treatment and irrigation environments, meeting the demands for long-term use.
Low Torque Operation Design for an Improved User Experience
The optimized fit between the ball and the valve seat minimizes opening and closing resistance while ensuring excellent sealing performance. It is ideal for systems requiring frequent operation, improving overall convenience.
Product Core Data
Technical Drawing
Bill of Materials
| NO. | PART | MATERIAL | QTY |
|---|---|---|---|
| 1 | Body | PVC | 1 |
| 2 | Valve Core | PP | 1 |
| 3 | Seat Seal | TPE / TPR | 2 |
| 4 | O–Ring | NBR / EPDM | 1 |
| 5 | Handle | ABS | 1 |
| 6 | Cap | ABS | 1 |
Measurement in (mm)
| OD(mm) | NPS (inch) | DN | GB | ANSI | JIS | B.S. | CNS | L | H | Z |
|---|---|---|---|---|---|---|---|---|---|---|
| Φ20 | 1/2″ | DN15 | 20 | 21.34 | 22.1 | 21.2 | 22.1 | 22.5 | 78 | 43.5 |
| Φ25 | 3/4″ | DN20 | 25 | 26.67 | 26.1 | 26.6 | 26.1 | 25.5 | 90.5 | 55 |
| Φ32 | 1″ | DN25 | 32 | 33.4 | 32.1 | 33.4 | 34.1 | 28.6 | 105.5 | 56.3 |
| Φ40 | 1-1/4″ | DN32 | 40 | 42.16 | 38.1 | 42.1 | 42.1 | 32 | 122.5 | 65.3 |
| Φ50 | 1-1/2″ | DN40 | 50 | 48.26 | 48.2 | 48.1 | 48.2 | 35 | 129 | 72 |
| Φ63 | 2″ | DN50 | 63 | 60.33 | 60.2 | 60.2 | 60.2 | 38.2 | 149 | 82 |
| Φ75 | 2-1/2″ | DN65 | 75 | 73 | 76.2 | 73 | 76.2 | 45 | 171 | 104.7 |
| Φ90 | 3″ | DN80 | 90 | 88.9 | 89.2 | 88.7 | 89.2 | 49 | 195 | 113.1 |
| Φ110 | 4″ | DN100 | 110 | 114.3 | 114 | 114.1 | 114.2 | 58 | 233 | 114.5 |
HD close-up of JARO PVC virgin raw material, showing pure and uniform pellets with every batch undergoing strict incoming inspection.
HD close-up of JARO PVC virgin raw material, showing pure and uniform pellets with every batch undergoing strict incoming inspection.
HD close-up of JARO PVC virgin raw material, showing pure and uniform pellets with every batch undergoing strict incoming inspection.
PVC Octagonal Ball Valve Applications
Industrial PVC ball valves providing reliable fluid control for wastewater treatment facilities.
Durable PVC piping valves for swimming pool water circulation and filtration systems.
Precision PVC fluid control valves for modern greenhouse and hydroponic irrigation systems.
Robust PVC ball valves empowering municipal engineering and commercial water feature systems.
FAQ
Find answers to the most frequently asked questions about our PVC octagonal ball valves below. Need more technical details or custom OEM solutions? Our engineering team is here to help.
The octagonal structure provides more stable, load-bearing surfaces. This makes it easier to secure tools during installation, reduces slippage, and helps lower construction difficulty as well as installation wear and tear.
It can be directly connected to equipment interfaces, reducing the use of extra fittings. This lowers the risk of leakage and keeps the piping structure more compact, making it ideal for equipment integration and tight system layouts.
It can be combined with PVC pipe fittings (couplings, elbows, tees, flanges, etc.) and other valve products (such as check valves and foot valves) to form a complete piping system, making it easy for customers to enjoy one-stop purchasing.
Yes, we support OEM customization, including thread standards, valve body colors, and brand logos. We also offer complete product bundle solutions to meet the customized needs of different markets.
