JARO SCH80 Coupling (JRS01) is designed for industrial Schedule 80 PVC-U piping. A straight socket coupling for joining two Schedule 80 PVC-U pipe sections in industrial piping runs. Its precise connection geometry supports dependable system assembly in water treatment, chemical handling, and general process piping. OEM customization is available.
Key Features of SCH80 Coupling
SCH80 System Compatibility
Designed as a pvc-u sch80 coupling for Schedule 80 PVC-U piping, helping installers specify compatible components across an industrial piping run.
Precision Connection Geometry
The socket connection is made for consistent assembly with compatible pipe, fittings, or equipment. Follow the applicable installation procedure and verify fit before commissioning.
PVC-U Material Selection
PVC-U is commonly selected for piping systems carrying media compatible with the material. Final chemical compatibility and operating conditions should be confirmed for each application.
Practical System Integration
The JRS01 fitting can be specified with SCH80 pipe, valves, unions, and other fittings to support clear, maintainable piping layouts.
SCH80 Coupling Dimensions
Product Drawing
Dimension Reference
| Item | Reference | Unit | Note |
|---|---|---|---|
| Product | SCH80 Coupling | — | Model JRS01 |
| System class | SCH80 | — | Confirm operating limits from the final project specification. |
| Connection | Socket | — | Use compatible pipe and connection standards. |
Dimensions
| size(inch) | D(mm) | L1(mm) | L(mm) |
|---|---|---|---|
| 1/2″ | 21.34 | 24 | 50.0 |
| 3/4″ | 26.67 | 27 | 56.5 |
| 1″ | 33.4 | 30 | 62.5 |
| 1-1/4″ | 42.16 | 33 | 68.5 |
| 1-1/2″ | 48.26 | 36 | 74.5 |
| 2″ | 60.32 | 39 | 80.5 |
| 2-1/2″ | 73.02 | 46 | 97.0 |
| 3″ | 88.9 | 49 | 103.0 |
| 4″ | 114.3 | 59 | 123.0 |
| 5″ | 141.0 | 67 | 139.3 |
| 6″ | 168.0 | 76.5 | 159.6 |
HD close-up of JARO PVC virgin raw material, showing pure and uniform pellets with every batch undergoing strict incoming inspection.
HD close-up of JARO PVC virgin raw material, showing pure and uniform pellets with every batch undergoing strict incoming inspection.
HD close-up of JARO PVC virgin raw material, showing pure and uniform pellets with every batch undergoing strict incoming inspection.
Applications for SCH80 Coupling
Industrial Water Treatment
Use in compatible treatment, filtration, and circulation pipework that requires pvc-u sch80 coupling connections.
Chemical Process Piping
Suitable for systems carrying media confirmed as compatible with PVC-U and the selected connection method.
Equipment & Skid Integration
Supports organized piping runs around pumps, tanks, filters, instruments, and other process equipment.
FAQ
Find answers to common questions about the JARO SCH80 Coupling. For project-specific selection, dimensional confirmation, OEM solutions, or technical documentation, please contact our sales and engineering team.
SCH80 Coupling (JRS01) is used in a compatible SCH80 PVC-U piping system. Its function is to provide the connection or flow-path arrangement indicated by its product name.
Match the fitting size, pipe outside diameter, connection standard, and system design requirements. Refer to the dimensional table on this page and confirm the final selection before ordering.
Verify material compatibility, operating conditions, joint preparation, and alignment. Use the appropriate installation method for the connection type and follow the applicable project and local requirements.
Yes. JARO supports OEM customization for branding, packaging, and product configurations subject to technical review and order requirements.
